Field Termination Connection Solution for re-routing, extending, and repairing links

VM-Pro 8-8 FA: A unique approach toward connection! Horizontal Cabling

  • Class FA (1000 MHz)
  • real-time re-embedded
  • suitable for 100 / 250 / 500 / 1000 MHz installation and patch cables
  • connection via IDC termination
  • insulated construction (insulating resistance 30x 1012 Ω)
  • connection of 4-pair shielded/unshielded installation and patch cables from AWG27-22
  • pairs can be brought directly up to the terminal without untwisting the pairs
  • EMC compatible acc. to DIN EN 61000-6-1 and DIN EN 61000-6-2
  • suitable for PoE+ acc. to IEEE 802.3at
  • temperature range from -40° C to + 70° C
  • re-connect up to 4 times

The connection module VM-Pro 8-8 Class FA IP67 offers transmission properties up to Class FA acc. to ISO/IEC 11801 and is suitable for installation and patch cables with 8 wires. Shielded and unshielded cables with solid and stranded conductors of AWG27-22 type and outer diameter of 5.5 - 9.0 mm can be connected with the VM-Pro 8-8 Class FA IP67. Due to its compact shape the connection module is suitable for use in confined spaces. Assembly of the VM-Pro 8-8 Class FA IP67 connection module requires no special tools and is completed in a few steps.
